 | Applications: Reverse Engineering,3D Inspection, 3D scanning very large objects |
| Sampling Speed: 18,000 measurements per second |
| Laser: Class II (eye safe) |
| Number of Cameras: 3 |
| XY Accuracy: Up to 50 microns (up to 0.002 inches) |
| Resolution: 0.1 mm in XYZ (0.004 inches in XYZ) |
| Volumetric Accuracy: 20 µm + 25 µm/m |
| Depth of Field: 30 cm (12 inches) |
| Package Software: ZScan |
| Weight: 1.27 kg (2.80 lbs) |
| Dimensions: 172 x 260 x 216 mm (6.75 x 10.2 x 8.5 inches) |
| Exported File Formats: .DAE, .FBX, .MA, .OBJ, .PLY, .STL, .TXT, .WRL, .X3D, .X3DZ, .ZPR |
| Regulatory Compliance: CE |
| Data Transfer: FireWire |
| Power Source: FireWire |
|
